Features:
Available materials:SS304,SS316,904L,Alloy,etc.
Available in size:1/8" to 1"
Thread:NPT,BSP,BSPT,UNF,ISO,SAE etc.
Working temperature:-4 to 392¨H(-20 to 200¡æ)
Working pressure:up to 3000psig(206bar)
Smooth thread flanks provide optimum sealing and minimize galling.
Female NPT size in. | Male NPT size in. | Ordering Number | Dimensions(mm) | ||
| A | E | F | |||
1/8 | 1/8 | RAN-01-01 | 27 | 5 | 14 |
1/4 | 1/8 | RAN-02-01 | 30 | 5 | 17 |
1/4 | RAN-02-02 | 33 | 6 | 17 | |
3/8 | 1/8 | RAN-03-01 | 30 | 5 | 22 |
1/4 | RAN-03-02 | 33 | 6 | 22 | |
3/8 | RAN-03-03 | 34 | 8 | 22 | |
1/2 | 1/8 | RAN-04-01 | 35 | 5 | 27 |
1/4 | RAN-04-02 | 38 | 6 | 27 | |
3/8 | RAN-04-03 | 39 | 8 | 27 | |
1/2 | RAN-04-04 | 42 | 10 | 27 | |
| 3/4 | 1/4 | RAN-06-02 | 40 | 6 | 32 |
3/8 | RAN-06-03 | 41 | 8 | 32 | |
| 1/2 | RAN-06-04 | 44 | 10 | 32 | |
